Many clients' product designs are "aesthetically pleasing but difficult to manufacture." Seemingly perfect 3D models often suffer from uneven wall thickness, insufficient draft angle, excessively thin ribs, and unreasonable undercut designs. These problems can lead to mold opening failures, mass production difficulties, high product defect rates, and even significant economic losses. Kinghe's 3D Model Optimization Services are designed to address this pain point. Starting from the actual needs of injection molding production, we reverse-engineer the product structure to ensure the design meets both aesthetic and functional requirements while adhering to mass production logic.
Our optimization team consists of senior injection molding engineers familiar with the properties of various plastic materials, injection molding process principles, and mold structure design. They can accurately identify mass production risks in 3D models and provide targeted optimization solutions based on the client's mass production needs, cost budget, and quality requirements. During the optimization process, we maintain close communication with clients, respecting their original design intentions. Without compromising the product's appearance and functionality, we optimize the structure to the maximum extent possible, ensuring smooth mold opening and stable mass production, while simultaneously reducing production costs and improving product quality. Whether it's a client-designed 3D model or a reverse-scanned sample model, we offer professional optimization services to safeguard your new product development.
We conduct a comprehensive inspection of the client's 3D model, identifying various mass production risks such as uneven wall thickness, insufficient draft angle, inadequate rib strength, unreasonable undercut design, air trapping risk, and shrinkage deformation trends, and provide a detailed inspection report.
We adjust the wall thickness to address unevenness issues, preventing defects such as shrinkage marks, deformation, and bubbles during mass production, while ensuring product structural strength and reducing material waste.
Based on the product's material and appearance requirements, we rationally set the draft angle to ensure smooth demolding, avoiding problems such as sticking, whitening, and scratches, thereby improving production efficiency.
Optimize the thickness, height, and distribution of ribs to enhance their strength and prevent shrinkage and breakage; optimize column structures by adding reinforcing ribs to improve load-bearing capacity and prevent tilting and breakage.
Provide reasonable solutions for undercut structures in products, such as optimizing undercut angles and adding core-pulling structure adaptation designs to avoid demolding difficulties or inability to demold, reducing mold development difficulty and cost.
The optimization team has over 10 years of experience in the injection molding industry, is familiar with various product structures and injection molding processes, and can accurately identify various mass production potential problems in 3D models, avoiding overlooking key issues.
Starting from the actual injection molding production, the optimization solutions take into account appearance, function, and mass production feasibility, ensuring that the optimized model can be successfully molded and stably mass-produced, truly solving customer pain points.
During optimization, we respect the client's design philosophy and product functional requirements, optimizing only for potential mass production risks without altering the product's core appearance and functionality.
We proactively mitigate risks such as mold failures and modifications, reducing modification costs and time; after optimization, product defect rates are significantly reduced, material waste is decreased, and overall production costs are significantly lowered.
Standard 3D Model Optimization Services can be completed in 1-3 days, and complex models in 3-7 days, quickly providing optimization solutions and shortening the client's new product development cycle.
We maintain close communication with the client throughout the optimization process, adjusting the optimization plan based on their feedback and needs to ensure client satisfaction, while providing professional technical advice.
3D Model Optimization Services are widely used in new product development scenarios for various plastic products, including toys and figurines, LED lampshades and housings, board game accessories, electronic component housings, household plastic products, educational toys, baby products, automotive parts, and smart home accessories. It is particularly suitable for optimizing models of cross-border new products, startup brand new products, and products with complex structures, clearing obstacles for mold making and mass production.
Client: A well-known domestic figurine brand
Client Needs: The client designed a complex 3D model of a figurine with an exquisite appearance. However, after trial production, serious problems such as shrinkage, deformation, mold sticking, and whitening occurred, resulting in a product yield of only 68%, making normal mass production impossible. Multiple mold modifications failed to resolve the issues, leading to significant losses.
Service Process: Upon receiving the project, Kinghe first conducted a comprehensive inspection of the client's 3D model, identifying eight core problems: uneven wall thickness, insufficient draft angle, excessively thin ribs, unreasonable undercut design, and severe air trapping in some areas. Our engineering team, combining the figure's appearance requirements with mass production needs, developed a targeted optimization plan: optimizing wall thickness distribution to ensure uniformity; strengthening the draft angle to prevent sticking and whitening; thickening and adjusting the distribution of ribs to enhance strength and avoid shrinkage; optimizing the undercut structure to adapt to the mold's core-pulling design; and adjusting local structures to solve air trapping issues. After optimization, a detailed optimization report and comparison diagrams were provided, communicated and confirmed with the client, and then the client was assisted with mold modification and trial molding.
Results: The optimized model was successfully trial molded on the first attempt. The product showed no shrinkage, deformation, or sticking, and its appearance was completely consistent with the client's original design. Product yield increased from 68% to 97.8%, production efficiency increased by 30%, and mold modification costs decreased by 60%.
Q: Can you modify our existing 3D drawings? Will the optimization affect the product's appearance?
A: Yes, we can. We will optimize only for potential mass production issues without affecting the core appearance and function of the product, ensuring that the optimized product is consistent with the client's original design and that the appearance is unaffected.
Q: Will the optimized 3D model guarantee successful mass production?
A: Yes. Our optimization solution is entirely based on injection molding mass production logic, comprehensively avoiding various mass production risks. The optimized model meets mold opening and mass production requirements, ensuring smooth mass production and reducing defect rates.
Q: How long does 3D model optimization take? Will complex models take longer?
A: For simple, standard models, optimization and a report can be completed in 1-3 days; for complex structures, models with multiple curved surfaces, and multiple inverted elements, it takes 3-7 days, depending on the model's complexity. We will plan the time reasonably to ensure on-time delivery.
Q: Can you reverse engineer and optimize models based on samples?
A: Yes. We support reverse scanning and modeling of samples to accurately reproduce the sample structure, and then perform comprehensive optimization according to mass production requirements to ensure the model can be successfully molded and mass-produced.
Q: Is there a fee for optimization services? If I subsequently have the mold made with you, can the optimization fee be deducted?
A: Optimization services incur a fee. However, if the client subsequently uses Kinghe for mold development and mass production, the optimization fee can be fully deducted from the mold cost, reducing the client's overall costs.
Kinghe firmly believes that high-quality design optimization is key to successful new product development and a core element in reducing client risks and enhancing product competitiveness. We are deeply rooted in the 3D Model Optimization Services field, adhering to the principles of "professionalism, precision, efficiency, and pragmatism." Leveraging the extensive experience and expertise of our senior engineering team, we provide targeted model optimization solutions to global clients, helping them mitigate mass production risks, reduce costs, and improve quality.
We understand that every 3D model embodies the client's creativity and expectations, and every optimization impacts their new product launch plans and market competitiveness. Therefore, we always uphold professional standards, pay attention to every detail, accurately identify every potential mass production risk, and provide scientifically sound optimization solutions, striving to ensure that every creative idea is successfully translated into a high-quality, mass-producible product. In the future, Kinghe will continue to deepen its technological research and development, continuously improve its model optimization capabilities, expand its optimization fields, and provide customers with more comprehensive, professional, and efficient optimization services. Kinghe aims to become the most reliable technology partner for customers' new product development, working hand in hand with global customers to empower creative ideas with professional optimization and achieve a win-win future with quality service.
